BIM Structural Modeling Services
Structural Modeling represents the digital replica of structural components of a building i.e., beams, columns, torsion, and foundations, using Autodesk Revit software. Tejjy-BIM Inc. provides Revit Structural BIM design-drafting-modeling services for concrete & steel structure building design. Integration of BIM modeling in structural engineering facilitates better analysis of design detailing and simulates the behavior to coordinate and collaborate with the architectural & MEP (mechanical, electrical, and plumbing) system. BIM services in structural engineering facilitates structural analysis, and optimization of building design, as well as generate fabrication and construction documents.
3D Structural models with LOD 100-500 for structural systems typically include information about the materials, dimensions, and load-bearing capacity of the elements, as well as the location and orientation of each element in the building. BIM Structural Modeling allows collaboration and coordination between all stakeholders (Structural BIM Modelers & Steel Detailer) in a construction project such as engineers, architects, and contractors.
We also offer the following Structural BIM detailing /modeling services across USA
Tejjy-BIM Structural Modeling/Detailing services Offers
- Highly accurate structural analysis and detailing.
- Analysis and optimization of the structural design using simulations and load-bearing calculation.
- Generation of fabrication and construction documents such as detailed shop drawings and bills of materials.
- Coordinated BIM model with Autodesk Navisworks Manage to conduct clash detection & provide the report with constructability review.
- 4D and 5D Quantity takeoff and estimating service, for extracting quantities of materials, labor, and equipment.
- Asset Management for the facility after completion, BIM models can be used as a tool for managing and maintaining a building over time.
OUR EXPERTISE IN
Advantages of Choosing BIM Structural Design Services
✅ Improved collaboration and communication
✅ Enhanced design and analysis capabilities
✅ Increased accuracy
✅ Reduced waste and rework
✅ More efficient construction
✅ Cost estimation and control
✅ Better Facility management and maintenance
Projects Delivered Through Structural Modeling Services
FAQ
On average, the cost of structural engineering drawings is between $800 and $3,000. They charge an hourly rate that ranges from $100 to $200. Structural engineers are paid anywhere from one percent to twenty percent of the overall construction price, which is equivalent to $1,500 to $20,000, for their work on new construction or major renovations.
You should opt for hiring a structural engineer for your building’s structural design and construction because they help in designing structure models using BIM software like Revit, ensuring that health and safety regulations are adhered to, take away the burden of supervising projects, and updating clients on the progress plus recommending the best materials to be used.
BIM structural analysis software for engineers like Revit, Robot Structural Analysis Professional, and Advanced Steel used for the structural analysis of various types of buildings. These structural BIM software’s also helps in structural designing and detailing.
