Client Summary

The scanning project at 1155 23rd Street, Northwest Washington, DC, focused on the PH3 condo unit and covered an area of 6,000 square feet. Utilizing the BLK 360 3D laser scanner, a total of 104 scans were conducted, capturing detailed information with a medium accuracy level and high dynamic range (HDR) photos. The scans encompassed both external and internal wall surfaces.

Scanning Details

  • Location: 1155 23rd Street, Northwest Washington, DC, PH3 CONDO
  • Scanned Area: 6,000 sq ft
  • Scanning Technology: BLK 360 3D Laser Scanner
  • Total Scans: 104
  • Scan Accuracy: Medium with HDR Photos
  • Scanning Time per scan: 4 minutes, 20 seconds
  • Lighting Conditions: Varied (artificial and natural daylight)

Data Processing

The chosen platform for data extraction was Cyclone Cloud Register 360, facilitating seamless transfer and organization of laser-scanned data. Subsequent steps involved scan alignment and finalizing the registered data. The Registered Cyclone Project (RCP) file was exported to Revit for modeling.

Project Result

A detailed model report was published, showcasing parameters crucial for accurate Building Information Modeling (BIM) models, including overlapping. The data extraction process was efficiently managed using Cyclone Register 360. The culmination involved exporting the RCP file to Revit for a comprehensive representation of the scanned data.

Description

PROJECT NAME
Laser Scanning Project: 23rd St NW, Washington, DC
LOCATION
USA
AREA
30,000 sq.ft
COMPLETED
2022
LOD
350
SERVICES
3D Laser Scanning, Scan to BIM, As built drawings, Walkthrough Video
