How BIM Design Helps in MEP Coordination?

mep services near me , mep drawings

Specifying the plan of diverse building structures in BIM market USA involves a high degree of design coordination amongst mep engineering teams. In present day scenario, one of the prime challenges for top BIM service providers is to avoid overlapping of locations for equipment belonging to diverse building systems. Equipment location conflicts at the construction phase leads to change orders. But the fact is with 2D plan on board Clash detection becomes difficult.

In contrast, while all design engineers work on a virtual reality model of the building, location conflicts are perceived instantly by the software. If two building system components are having overlapping components, the corresponding design teams are notified instantly.

The use of Revit BIM services accelerates the design process, reducing repetition and the amount of time necessary for design review. Furthermore, BIM software is normally adept at calculating material lists, saving valued man-hours. In such a way, a competent BIM engineering company is able to emphasize on designing the best solution without dedicating time to tedious and repetitive tasks. Several projects in the BIM market USA require a process of approval with the Department of Buildings, that is often time consuming. However, if you use BIM software application for MEP drawings, you are able to accelerate the process of project approval for detecting design errors immediately at the pre-construction stage.

Let’s find out Why MEP Engineering Firms Should adopt BIM design ?

Before moving ahead lets understand the transformation brought in by conversion from CAD to BIM. Eventhough the parent of AutCAD MEP and Revit MEP is Autodesk, but still whom to opt for?

Whom to Choose– AutoCAD MEP or Revit MEP:

Child of same parents AutoCAD MEP was an initial version with a strong hold on architectural drafting. Whereas Revit MEP holds the roots of AutoCAD MEP designing capabilities with enhanced services. Mep consultants are able to do better detailed design drawings with Revit mep services.

For a multi-storied building or complex Revit MEP services allows all floor plan designing at one moment whereas in case of AutoCAD MEP floor plan designing of one level can be done at a particular moment.

Discussing ahead are the added benefits of Revit BIM MEP for MEP engineering project

  • Better Estimating For MEP Engineering:

Any design modification leads to changes in material estimation , material procurement. Being an interlinked and interdependent environment change order reflects on quantity take off as well as cost estimation. Even though some estimator rightly said,” Few changes are inevitable and uncontrollable beyond the limits of 5D estimation”. This is very rightly true but 5D estimation and quantity take off through BIM model facilitates the estimators and surveyors to be accurately precise till an extent. This is not the scenario with CAD environment. Change orders constitute to be one of the primary causes of increased project cost.

Based on the structure of the contract, extra cost affects the building owners and the contractors. Augmented change orders lead to missed deadlines, delaying the process of building commissioning. BIM happens to be a powerful project tracker for BIM service providers in USA, throughout the construction project lifecycle, enabling supervision engineers to keep projects within budget and time.

  • 3D Modeling For Design Coordination:

Naviswork 4d simulation results in better mep engineering. The use of Revit BIM services for MEP engineering facilitates in detecting the need for change orders during the design phase, while modifications are executed on a virtual model. It becomes easier to edit a building model faster in 3D BIM, which is considerably cheaper than dismounting and reassembling real installations. Editing the design in the 3d BIM model only costs engineering time, while project modifications encompass material and labor costs.

  • Animation, Walkthrough, Virtual Design and Construction VDC:

 MEP engineering companies with effective scheduling and monitored change order management is able to control the construction cost. This bring smiles not only to estimators and surveyors but also for mep consultants. A VDC model is particularly useful while managing the property and scheduling maintenance operations. This supports a preventive maintenance tactic rather than a volatile approach. BIM modeling helps to fix problems before their occurrence instead of fixing the damage when the components of the building system collapse.

Since the BIM model encompasses data on MEP components for mechanical shop drawing, it gets updated with routine inspections and building system amendments. A virtual model of a building created through BIM facilitates in tracking the key components and schedule their replacements earlier. Engineering work is essential for inspecting the existing property condition and build a consistent virtual model, but once this stage is accomplished the building becomes easy to manage.

Invest in MEP BIM engineering services to reduce building costs for the long run. Remember that a high quality design created through BIM helps to simplify construction, operation and maintenance. Consult the top BIM consulting for BIM services in USA like Tejjy Inc. Get MEP drawings, mechanical shop drawings , spool drawings and customized Revit BIM services for your design build services.
